Engine Type530cc liquid-cooled, 4-stroke, DOHC inline twin-cylinder; 4 valves/cylinder
Bore x Stroke68.0mm x 73.0mm
Fuel DeliveryFuel injection
IgnitionDigital TCI: Transistor Controlled Ignition
Suspension / Front41mm upside-down telescopic forks; 4.7-in travel
Suspension / RearMid-ship, horizontal-positioned rear shock; 4.6-in travel
Brakes / Front267mm hydraulic dual disc brake
Brakes / Rear282mm hydraulic disc
Tires / Front120/70-15
Tires / Rear160/60-15
L x W x H86.6 in x 30.5 in x 55.9 - 58.1 in
Seat Height31.5 in
Rake (Caster Angle)25.0°
Maximum Ground Clearancen/a
Fuel Capacity4.0 gal
Fuel Economy**46 mpg
Wet Weight485 lb
- Potent Twin-Cylinder Power
The 530cc twin-cylinder engine has a linear power feel that pulls through the rpm range delivering excellent acceleration and a sporty ride experience. Yamaha’s advanced fuel injection system also ensures smooth and refined engine management, too.
- Fully Automatic Transmission
There is no need to use a clutch or shift gears with the durable and reliable continuously variable transmission (CVT) and that makes riding the TMAX fun and convenient.
- Minimized Servicing Needs
The TMAX is built to be ridden, with an industry-leading 26,600-mile valve clearance inspection intervals. A convenient oil change monitoring system lets the rider know when to change the oil, and a belt final drive requires no messy cleaning or oiling.
High-Tech Aluminum Frame
A CF die-cast aluminum frame is both strong and rigid while helping to reduce overall weight and improving the handling characteristics of the TMAX. Additionally, the swingarm is aluminum helping to reduce weight.
Sportbike-Style Inverted Fork
The all-new 41mm upside-down front fork reduces unsprung weight and is both functional and stylish. The fork provides 4.7” of wheel travel to smooth out the bumps on city streets and highways.
Compact Rear Shock Design
A mid-ship horizontally positioned rear shock offers 4.6” of wheel travel for added rider and passenger comfort while keeping the center of gravity low to improve handling.
Powerful Radially Mounted Brakes
Radial-mount, 4-piston front brake calipers are coupled with two big 267mm floating mount-type brake discs and add to the sporty, cool styling of the TMAX. Braking performance is excellent with very good rider feel.
High Traction Wheels and Tires
Wide radial 15-inch tires front and rear offer both excellent grip and comfort.
Extensive On-Board Storage
A large under-seat storage space will securely store a full face helmet or groceries.
Two-level adjustable windscreen for variable windscreen heights, to suit a wide range of riders.
Advanced LED Lighting
Bright twin-beam LED headlights offer excellent visibility and are incorporated into the front cowl and add to the very sporty appearance of the TMAX.
Stylish, Functional Instrumentation
A sporty instrument panel uses round analog dials for both speedometer and tachometer, with a slick black background featuring red accents for excellent visibility and style.
Hands-Free Smartkey System
The Smartkey system allows the rider to keep the key fob in their pocket while maintaining the ability to start and turn off the engine without the need to use a standard key switch. Additionally, the Smartkey allows the rider to operate the steering lock, seat lock release and electrics cut-off with the push of a button located in the center of the inner panel.
